OR-1801X/1802X Eco Solvent Printer

Parameter
Print Head: Single i3200 Print Heads/Dual i3200 Print Heads
Max Print Size: 70.8 in.(1800 mm)
Colors : CMYK

Feature
Eco Solvent Printer(With 1/2 i3200-E1 Heads)

  • OR-1801X/OR-1802X

  • ORIC

Availability:

PDF Export

Printer Heads

喷头2Epson Inkjet Head - i3200-E1

The Epson authorized i3200-E1 Water is a cost-effective 1.33inch-wide MEMs head series providing high productivity and high image quality with (600 dpi/colour) high-density resolution. This printhead is suitable for water based inks. Ink ejection of up to 4 colours realize with high resolution.PrecisionCore print head has proven high durability and extended service life by Epson's industrial printers.


Product Specifications:
Product name EPSON i3200-E1
Ink Type Eco Solvent Ink
Type PrecisionCore MicroTFP print head
WidthxDepthxHeight 69.1x 59.4 x 35.6 mm
Number of Nozzle 3200
Nozzle pitch/nozzle row 1/300 inch
Nozzle rows 8 rows
Nozzle Resolution 300 npi /row 600 npi/2 rows
Max. number of colour inks 4 colours
Droplet volumes 6 pl (Single mode)
6.3,1 2.3 pl (Multi mode)

* 1.8m Dual 13200 Print Heads Speed

360x1800dpi - 3pass              55 ㎡/h

720x1200dpi - 4pass            40 ㎡/h


Technical Specifications


Technical Specifications
ModelOR-1801XOR-1802X
Print HeadSingle 13200 Print HeadsDual 13200 Print Heads
Printing TechnologyPiezoelectric Inkjet
Acceptable MediaWidth71.6 in.(1820 mm)
ThicknessMaximum 59 mil(1.5 mm)
Weight132.2 lb.(60 kg)
Printing Width70.8 in.(1800 mm)
Ink CartridgesTypeEco Solvent Ink
Supply4*4 CISS (220ml ink cartridge with 1.5L ink tank)
Color4 colors (Cyan, Magenta, Yellow, Black)
Printing ResolutionMaximum 2400 dpi
Printing Speed3pass(360x1800dpi): 590 sqft (27 sqm/h)
3pass(360x1800dpi): 590 sqft (55 sqm/h)
4pass(720x1200dpi): 429 sqft (20 sqm/h)4pass(720x1200dpi): 429 sqft (40 sqm/h)
6pass(720x1800dpi): 290 sqft (14 sqm/h)6pass(720x1800dpi): 290 sqft (27 sqm/h)
Media Heating SystemIntergrated post heater & Infrared Dryer & Fan system
InterfaceUSB 3.0
Power SupplyAC 220V ± 10%,50/60 HZ
Dimensions(with stand)125(W)x38(D)x55(H) in.
(2750(W)x730(D)x1388(H) mm )
Weight(with stand)380 kg
Package Dimensions114(W)x30(D)x30(H) in
( 2900(W)x760(D)x760(H) mm )
Package Weight400 kg
EnvironmentPower onTemperature: 59 ℉to 90 ℉ [15℃ to 32℃] (68℉[ 20℃] /Humidity: 35 to 80% (no condensation)
Power offTemperature: 41 ℉to 104 ℉ [5℃ to 40℃]  /Humidity: 20 to 80% (no condensation)
AccessoriesPrint Heads, USB cable, media clamp, manual, drain botle, ink cartridges, RIP software, etc.


Features

Feature of OR-1801X/1802X

Latest technology of DTF , Want some quality clothing shirt? Try our DTF Print, same as silkscreen.


1.1

New pinch roller structureof three in group bringsmore stable feeding precision.

2.2

High-precision andhigh-stability tensioningpulley system.


3.3

High quality DC servomotor with good stabilityand long life.

4.4

The automatic cleaningassembly adds a single-wayvalve to increase thestability of the ink supply.

5.5

Infrered heater+cooling fan+LCD temperature controlpanel, more precise controlof the drying temperature.

6.6Automatic moisturizingcleaning assemblyensures the stabilityof head cleaningand improvesworking stability.



Application

1801x

Our range of wide format inkiet printers matche our knack for enginering and qualty with your desire for impeccable performance and careles production. You can producerol-to-roll indoor prints and long term outdoor signs. Wide applications in ight box posters, customized car stickers, background wallcloth abel printing, advertising sign. subwayadvertising, shopping mall advertising signs etc.

Additional Value
01
Year Warranty
Within 1 year from the date of purchase, if the machine has non-man-made damage, you can enjoy free warranty service.
02

Online Technical Support
The expert team will serve you online and solve any problems you encounter for free.
03
Inkjet Printer Starter Kit
Starter kit pack including complete set of test inks, commonly used replacement parts,and the user's guide, installation Video Instructions.
04
Dealer’s Team Training
Regularly provide our dealers , technical training of new models, application solutions training, sales guidance training.

DTF Accessories
DTF Accessories inculding DTF textile inks, DTF shaking powder and PET Film with high quality accessories for DTF printing with affortable price.
DTF PET Films
DTF film can be transferred on a wide range of fabrics. Capable of printing to shirts, sweaters, hoodies, pullovers, canvas, denim, and more! Our DTF films have excellent ink absorption for high-precision printing. Use our film you will achieve high-quality, breathable, and smooth prints.
DTF Textile Prinitng Ink
DTF textile printing ink is highly compatible with print Epson heads. You can directly print your designs on different textiles and fabrics using Direct to Film Ink technology.ORIC offers different colors of DTF inks such as W, Y, K, M, C, Or, Gr, and also fluorescence pink & fluorescence yellow.
DTF Hot Melt Powder
Unlike DTG technology, DTF requires no pre-treatment.The most important factor is DTF Powder. DTF powders are specially designed to use with DTF printing process. Our DTF powders are slow drying and easy to cold tear. Which will help you get excellent transfer printing results.
ORIC factory is a digital inkjet printing equipment manufacturer and solution provider For UV(Roll-roll/Hybird/Flatbed)/ Sublimatoin / ECO Solvent / Solvent / DTF / UV DTF / Texture Painting
